Case Study:
AUTOMOTIVE
FACILITY

  •



Wire & Cable in
Automotive Manufacturing

Copper Line Break

OUR SOLUTION      FOLLOW-UP QUESTION





Automotive Wire and Cable Application Illustration

SUBMIT A QUESTION

SELECTION GUIDE



POWERING FUTURE DEVELOPMENT

Sustainable transportation is being developed every day, but no automotive manufacturer has seen innovation like that of this state-of-the-art facility in Normal, Illinois. But in order to fulfill their vision, they needed quality wire and cable.

On a mission to manufacture top-of-the-line electric truck and SUV vehicles built for off-road adventures, this company turned to Service Wire. Every vehicle produced by this facility is completely electric, and their models have rapidly begun to compete with other industry-leading names.

Service Wire’s reputation for quick lead times and ability to manufacture custom wire and cable solutions made it possible to get our foot in the door. Plus, our corporate headquarters in West Virginia provides quick, direct access to many prominent players in the automotive industry.

CUSTOM MADE, SILICONE-FREE WIRE & CABLE

Service Wire secured a custom, made-to-order run of three silicone-free products: 600 Kcmil XHHW-2 Tray Cable with CPE jacket, 750 Kcmil XHHW-2 Tray Cable, and 500 Kcmil XHHW-2 with jacketed galvanized interlocked armor.

These products were requested to be silicone-free, an important requirement for any automotive plant. Silicone in materials of any kind, including wire insulation, will surface when exposed to paint. This can lead to the silicone interfering with adhesive materials, including the ability for the paint to stick.

Service Wire developed a unique delivery schedule that helped facilitate the plant’s detail-oriented work schedule, delivering on-time and under budget.

GOING ABOVE AND BEYOND

“We are proud to play a role in this company’s new manufacturing facility,” said Regional Sales Manager, Rodney Smith. “Our ability to design, manufacture, and ship a solution exactly to the customer’s specification, in as short as four weeks, is another example of why customers can count on Service.”

“Special production runs, custom packaging, quick shipment…you name it. Our team is equipped with the knowledge and expertise to ensure customers get a solution as unique as their need,” said Smith.

Service Wire’s involvement doesn’t end once our reels reach the jobsite. We are committed to developing long-lasting partnerships with many of our customers. To this day, Service Wire regularly supplies this customer.

Contact your rep to inquire about our industry-leading inventory or made-to-order wire and cable solutions.

AUTOMOTIVE WIRE &
CABLE SELECTION

Red Line Break

Service Wire's products can be used in an array of applications inside an automotive manufacturing plant. Our most popular wire and cable products include:

  • Silicone-Free ServicePro-X® Single Conductors
  • ServicePlex® Twisted Multiconductor Cables
  • Dual Rated Tray Cable
  • Jacketed Interlocked Armor (Type MC)
  • ServiceDrive® VFD Cable System





Building Wire and Cable for Heavy Commercial Applications

ServicePRO-X®

No Pulling Lubricant Required
(#6 AWG and Larger)

  • XHHW-2 600V/1kV Copper
  • USE-2 or RHW-2 600V/1kV Copper
  • RHW-2 or RW90 1kV/2kV Copper

AVAILABLE:
#14 AWG - 750 Kcmil
Tinned Conductors
VW-1 Rated
Wide Range of Colors
Silicone-Free

ServicePLEX prefab, twisted single conductor building wire

ServicePLEX®

Prefab Twisted Single Conductors

  • XHHW-2 600V/1kV Copper
  • USE-2 or RHW-2 600V/1kV Copper

AVAILABLE:
#14 AWG - 750 Kcmil
2-7 Conductors
Built-In Grounds
Pre-Installed Pulling Heads
Wide Range of Colors
Silicone-Free

Shielded and Non-Shielded Dual Rated 600V/1kV AAP Tray Cable

TRAY CABLE

TC-ER Rated

  • XHHW-2 Inner Conductors
    Colored, Numbered, or Striped Conductor

AVAILABLE:
Dual Rated 600V/1kV or 2kV
#14 AWG - 750 Kcmil
2-37 Conductors
Tinned or Non-Tinned
Shielded or Non-Shielded
PVC, ServiceCPE®, or EnviroPLUS® Jacket

Aluminum or Galvanized Steel Interlocked Armor (AIA) Feeder MC (Metal-Clad) Cable

FEEDER MC

Flexible Interlocked MC (UL 1569)

  • XHHW-2 Inner Conductors
    Colored, Numbered, or Striped Conductors

AVAILABLE:
#8 AWG - 600 Kcmil
2-4 Conductors
120V and 480V Color Codes
50% Ground
PVC, ServiceCPE®, or EnviroPLUS® Jacket

Jacketed Armored Cable

JACKETED MC

Flexible Interlocked Type MC (UL 1569)

  • XHHW-2 Inner Conductors
    Colored, Numbered, or Striped Conductors

AVAILABLE:
AIA and GSIA
#14 AWG - 750 Kcmil
2-37 Conductors
120V and 480V Color Codes
50% Ground
PVC, ServiceCPE®, or EnviroPLUS® Jacket

Tray and Armor Variable Frequency Drive Cable - ServiceDRIVE VFD Cable System

ServiceDRIVE®

VFD Cable System

  • VFD Tray/Power Cable
    600V/1kV or 2kV Copper
  • VFD Jacketed Armor
    2kV Copper

AVAILABLE:
#14 AWG - 750 Kcmil
PVC, ServiceCPE®, or EnviroPLUS® Jacket
